900 MHz 1/2-Wave Whip Antenna
Key Features
1. Stable RF Performance and High Weather Resistance
Designed for the 920 MHz ISM band, this antenna delivers low reflection performance with VSWR ≤ 2.0 and an average gain of ≥ 1 dBi.
2. Pre-Certified with Multiple Wireless Communication Modules
Pre-certified with major LPWA communication modules used in Japan, including LoRa and Wi-SUN.
For current certification status, please contact the respective module manufacturer or authorized distributor.
3. Ingress Protection
Each unit undergoes 100% waterproof inspection prior to shipment and is verified to meet IPX7 requirements. The antenna provides reliable water resistance, making it ideal for high-reliability applications.
4. UL 94 V-0 Flame Rating
The housing uses weather-resistant ASA resin and meets the UL 94 V-0 flame rating. It ensures safe and reliable operation in demanding environments.
Applications
IoT, smart building systems, and construction ICT applications. Suitable for outdoor use.
Specifications
| Operating Frequency | 845–945 MHz |
|---|---|
| Antenna Type | 1/2-Wave Monopole Antenna (No Ground Plane Required) |
| Gain | ≤ 3 dBi |
| Radiation Pattern | Omnidirectional |
| Input Impedance | 50 Ω nominal |
| Connector | SMA Plug (Straight) / SMA Plug (Right Angle), Standard / Reverse Polarity |
| Coaxial Cable Length | N/A |
| Dimensions |
160 (L) × Ø9 mm (Max. diameter Ø12 mm)
(164 mm (L) with Right-Angle Connector)
|
| Operating Temperature | –30 °C to +70 °C |
| Accessories | N/A |
| RoHS 2 Compliance | RoHS 2 compliant (free of restricted substances) |
| Ingress Protection | IP67 (Waterproof inspection conducted before shipment) |
| Remarks |
This product is a standard model and specifications may change or production may discontinue without notice.
This product is not intended for use in safety-critical applications, including but not limited to: aerospace systems, transportation control systems, power generation control equipment, and life-sustaining medical devices. Please contact your distributor for ordering information. Samples are also available for purchase from NAD.com and Marutsu Online. |
Product Lineup
| Part Number | Color | Regulatory model No. | Connector Type | Connector Configuration | Notes |
|---|---|---|---|---|---|
| 1019-008A | Ivory ■ | T13-047-1038 | Standard | SMA Plug (Straight) | Mass Production |
| 1019-089A | Black ■ | Contact Us | |||
| 1019-009A | Ivory ■ | T13-047-1039 | Reverse Polarity | Contact Us | |
| 1019-090A | Black ■ | Contact Us | |||
| 1019-010A | Ivory ■ | T13-047-1040 | Standard | SMA Plug (Right Angle) | Mass Production |
| 1019-091A | Black ■ | Contact Us | |||
| 1019-011A | Ivory ■ | T13-047-1041 | Reverse Polarity | Contact Us | |
| 1019-092A | Black ■ | Contact Us |
*We recommend selecting the SMA plug plating to match the mating SMA jack (SMA-BJ) plating to ensure optimal electrical performance and long-term reliability.*
