Transparent Film Antenna
Features
1. Nearly Invisible Antenna Pattern
The Transparent Film Antenna uses a proprietary manufacturing process that makes the antenna pattern nearly invisible. Compared with conventional FPC designs, it minimizes visual impact during installation. You maintain visual aesthetics while achieving reliable wireless performance.
2. Conforms to Curved Surfaces
This antenna features a flexible structure that conforms to curved and contoured surfaces. You can mount it on automotive windshields, display case glass, and other non-flat surfaces. You improve wireless performance without restricting industrial design.
Applications
1. Installation on Automotive and Display Glass:
The Transparent Film Antenna mounts on automotive windshields, vending machine windows, and display case glass. Its nearly invisible pattern preserves visibility while delivering high-performance wireless connectivity. You enable smartphone connectivity and vehicle monitoring systems in automobiles, as well as digital advertising and communication functions in display cases.
2. 5G, Repeaters, and Base Station Integration:
The Transparent Film Antenna supports millimeter-wave 5G communication, which operates at high frequencies with limited diffraction, as well as 5G repeaters and macrocell and nanocell base stations. You deploy high-speed, stable wireless infrastructure without compromising exterior design.
Supported Frequency Bands: V-LOW, UHF, LPWA, 3G/LTE, GPS, Sub-GHz Low Power Radio, Wi-Fi, GP, and others
*Specifications shown are examples and may vary depending on the product. *Specifications shown are examples and may vary depending on the product.
Specifications & Compliance
| Operating Frequency | Custom (Contact us) |
|---|---|
| Model | Custom (Contact us) |
| Gain | Up to 3 dBi |
| Radiation Pattern | N/A |
| Input Impedance | Nominal 50Ω |
| Connector | Custom (Contact us) |
| Coaxial Cable Length | Custom (Contact us) |
| Dimensions |
Custom (Contact us)
|
| Operating Temperature Range | -30 °C to +85 °C |
| Accessories | N/A |
| RoHS 2 Compliance | RoHS 2 compliant (free of restricted substances) |
| Ingress Protection | N/A |
| Remarks |
Do not use this product in applications that require exceptionally high safety standards.
(Including aerospace equipment, transportation control systems, power generation control systems for nuclear, thermal, or hydroelectric plants, and medical devices that directly affect human life.) |
